Faw High Payload Logging Trailer Truck
You can rest assured to buy customized Faw High Payload Logging Trailer Truck from us. We look forward to cooperating with you, if you want to know more, you can consult us now, we will reply to you in time! JUPITER is a large-scale semi trailer and special vehicles manufacturer and supplier in China. We have been specialized in semi trailer and special vehicles for more than 38 years. Our Faw High Payload Logging Trailer Truck with FUWA 13T axle have a good price and quality advantage and had already exported to the Asia, Africa and South America countries. We look forward to becoming your long-term partner in China.
Send Inquiry
Product Description
This JUPITER 40ft 3-axles LOG semi trailer is suitable for carrying ISO 20FT and 40FT containers, bulk cargo such as steel,stone which are mostly used in short and long distance transportation. 40ft 3-axles LOG semi trailer with Mechanical suspension is the best choice for the transportation and operation of bulk cargos,20ft and 40ft container van box with high efficiency and economic return, we use famous brand parts on 40ft 3-axles LOG semi trailer r with Double Coin 12R22.5 Tire, such as FUWA or BPW Brands Axle, JOST King Pin.so we recommend the end users or drivers to choose this 40ft 3-axles LOG semi trailer with FUWA JOST 2 inch 3.5 inch king pin and welcome to inquiry about our40ft 3-axles LOG semi trailer.
|
Type |
Faw High Payload Logging Trailer Truck |
|
|
Model |
FTW9406 |
|
|
Parameter |
Dimension(mm) |
length×width×height:12420×2500×3560mm |
|
King Pin Setting(mm) |
1000 |
|
|
Fifth Wheel Height(mm) |
The height will be adjusted according to the tractor specification |
|
|
Axle Space(mm) |
7200+1310+1310 |
|
|
Tare Weight（kg） |
7,500 |
|
|
Payload（kg） |
45,500 |
|
|
Fabric |
Main Beam(mm) |
500, submerged arc welding Q345B |
|
Flange and Web(mm) |
14/8/16 |
|
|
Flooring |
3mm Checkered Plate |
|
|
Wood Carrier |
yes |
|
|
Paint |
primer + top coat |
|
|
OEM |
Landing Gear |
FUWA 19” |
|
Kingpin |
50＃，FUWA |
|
|
Brake System |
30/30 type onrear two axles with brake valve |
|
|
ABS |
No |
|
|
Suspension |
Mechanical suspension with8 leaf spring |
|
|
Axle |
||
|
Tire |
Double Coin Brand12R22.5-18PR, Number:12 |
|
|
Rim |
9.0*22.5 Number:12 |
|
|
Tool box |
1 set on right side, 1m, steel |
|
|
Spare Tire Carrier |
equipped2 sets per chassis |
|
|
Color |
|
According to customer’s requirements |
|
Others |
|
l “LONG VEHICLE” sign on the rear end. l LED lights，equip side turn light. l Main beam: stick “JUPITER” logo l Mud flap: stick “JUPITER ” l Nameplate: English model |
Note:
All the details not mentioned above should comply with Chinese regulations.
JUPITER does NOT take any responsibility on the trailer’s registration in the terminal country.
